MikroTik Cloud Core Router CCR2116-12G-4S+ 12-Port Gigabit Router with 4 SFP+

The MikroTik Cloud Core Router CCR2116-12G-4S+ is a high-performance enterprise router designed for demanding network environments, including data centers, service providers, enterprise networks, and high-traffic infrastructure. Powered by a 16-core Annapurna Labs Alpine CPU running at up to 2 GHz and equipped with 16 GB of RAM, the router delivers substantial processing capacity for advanced routing, firewalling, VPN, traffic management, and other RouterOS applications. It provides 12 Gigabit Ethernet ports and four 10G SFP+ ports, with the SFP+ interfaces connected directly to the CPU for high-speed network processing. The CCR2116-12G-4S+ runs RouterOS and features a 1U rack-mountable enclosure, redundant power supplies, and an M.2 NVMe slot for additional storage applications.

Product Features

16-Core Enterprise Processing

The CCR2116-12G-4S+ is powered by a 16-core Annapurna Labs Alpine CPU running at up to 2 GHz, providing the processing performance required for demanding routing and network-management workloads.

12 Gigabit Ethernet Ports

Twelve 10/100/1000 Mbps Ethernet ports provide extensive wired connectivity for LAN networks, servers, management connections, and other network infrastructure.

Four 10G SFP+ Ports

Four SFP+ ports provide high-speed 10 Gigabit fiber or direct-attach connectivity for network uplinks, aggregation, data center interconnections, and other high-bandwidth applications.

High-Speed CPU-Connected SFP+ Interfaces

The four SFP+ interfaces are directly connected to the CPU, helping provide efficient high-speed traffic handling for demanding network applications.

16GB RAM

With 16GB of RAM, the CCR2116-12G-4S+ provides substantial memory capacity for RouterOS features, routing tables, firewall rules, VPN services, and other advanced network functions.

Advanced RouterOS Features

RouterOS provides a comprehensive set of networking capabilities, including dynamic and static routing, BGP, OSPF, VLANs, firewall policies, NAT, VPN, QoS, traffic shaping, and network monitoring.

Dual Power Supplies

Two AC power supply units provide redundancy for installations where network availability and operational continuity are important.

M.2 NVMe Storage Support

An integrated M.2 PCIe NVMe slot allows compatible storage to be added for supported RouterOS applications and network-management requirements.

1U Rack-Mountable Design

The compact 1U chassis is designed for standard 19-inch server and network racks, making it suitable for data centers, enterprise server rooms, and professional network infrastructure.

Hardware Encryption Support

The router includes hardware-assisted encryption capabilities to help accelerate supported security and VPN workloads.

Product Specifications

• Brand: MikroTik
• Product Family: Cloud Core Router
• Model: CCR2116-12G-4S+
• Product Type: Enterprise cloud core router
• Operating System: MikroTik RouterOS
• RouterOS License: Level 6
• Processor: Annapurna Labs Alpine AL73400
• CPU Cores: 16
• CPU Frequency: 2 GHz
• System Memory: 16 GB RAM
• Ethernet Ports: 12 x 10/100/1000 Mbps Gigabit Ethernet
• SFP+ Ports: 4 x 10G SFP+
• SFP+ Port Speed: Up to 10Gbps
• Console Port: RJ45 serial console
• USB Port: 1 x USB 3.0 Type-A
• Storage: 128 MB NAND
• Additional Storage: 1 x M.2 PCIe NVMe slot
• Routing Protocols: Static routing, BGP, OSPF, RIP, and other RouterOS-supported protocols
• Firewall: Stateful firewall with advanced filtering and security policies
• NAT: Supported
• DHCP: DHCP server and client
• VLAN: IEEE 802.1Q VLAN support
• VPN: IPsec, WireGuard, OpenVPN, L2TP, SSTP, and other RouterOS-supported VPN technologies
• Quality of Service: Supported
• Traffic Management: Supported
• Link Aggregation: Supported
• Hardware Encryption: Supported
• Management: Web interface, CLI, WinBox, and MikroTik management tools
• Power Supply: 2 x redundant AC power supplies
• Maximum Power Consumption: Approximately 60W
• Cooling: Active cooling with hot-swappable fan modules
• Rack Form Factor: 1U
• Enclosure: Metal
• Operating Temperature: -20 to 60°C (-4 to 140°F)
• Dimensions: Approximately 443 x 199 x 44 mm
• Installation: 19-inch rack mounting
• Redundant Power: Supported
