MikroTik Cloud Core Router 1U Rackmount with 12 SFP Cages and 1 SFP+ Port – CCR1016-12S-1S+

The MikroTik CCR1016-12S-1S+ is a high-performance Cloud Core Router engineered for Internet Service Providers (ISPs), enterprise networks, data centers, and carrier-grade networking environments. Built around a powerful 16-core Tilera processor, it delivers exceptional routing performance for demanding applications such as BGP, OSPF, MPLS, VPNs, and advanced firewall configurations. The router features twelve Gigabit SFP ports, one 10G SFP+ port, redundant AC power supplies, a 1U rackmount chassis, and MikroTik RouterOS Level 6, making it an excellent solution for high-speed fiber networking and mission-critical deployments.

Product Features

Sixteen-Core High-Performance Processor

Powered by a 16-core Tilera CPU running at 1.2 GHz per core, delivering outstanding routing, firewall, VPN, and traffic management performance for enterprise and ISP applications.

Twelve Gigabit SFP Ports

Equipped with twelve SFP cages supporting 1 Gbps fiber modules for high-density fiber connectivity and scalable network expansion.

One 10G SFP+ Uplink Port

Includes a dedicated 10 Gigabit SFP+ port for high-speed backbone connections, aggregation, and data center uplinks.

RouterOS Level 6

Runs MikroTik RouterOS Level 6, providing advanced networking capabilities including dynamic routing protocols, firewall protection, VPN services, VLANs, Quality of Service (QoS), bandwidth management, MPLS, and traffic monitoring.

Redundant Power Supplies

Features dual hot-redundant AC power supplies to maximize reliability and ensure continuous operation in mission-critical network environments.

LCD Touchscreen Management

Includes a built-in touchscreen LCD display for monitoring device status, network information, and system diagnostics.

USB and Console Connectivity

Provides a USB Type-A port for external storage and system functions, along with an RJ45 serial console port for advanced management and configuration.

Rackmount Enterprise Design

Designed in a durable 1U rackmount enclosure, making it ideal for server rooms, telecommunications facilities, and professional network cabinets.

Product Specifications

• Model: CCR1016-12S-1S+
• Product Type: Cloud Core Router
• Form Factor: 1U Rackmount
• Processor: Tilera TLR4-01680
• CPU Cores: 16
• CPU Frequency: 1.2 GHz
• Architecture: TILE
• RAM: 2 GB
• Storage: 128 MB NAND
• Operating System: MikroTik RouterOS
• RouterOS License: Level 6
• SFP Ports: 12 × 1 Gbps SFP
• SFP+ Ports: 1 × 10 Gbps SFP+
• USB Port: 1 × USB Type-A
• Console Port: 1 × RJ45 Serial Console
• Memory Card Slot: 1 × microSD
• Power Supply: Dual Redundant Internal AC Power Supplies
• Input Voltage: 100–240 V AC
• Maximum Power Consumption: 47.5 W
• Cooling: Dual Intelligent Fans
• LCD Display: Integrated Touchscreen
• Dimensions: 443 × 197 × 44 mm
• Operating Temperature: -20°C to 60°C
• Certifications: CE, EAC, RoHS
• IP Rating: IP20
• Ideal Applications: Internet Service Providers (ISPs), enterprise core routing, data centers, fiber aggregation, MPLS networks, VPN gateways, carrier networks, and high-performance business networking.
