MikroTik CCR1016-12S-1S+ Cloud Core Router

The MikroTik CCR1016-12S-1S+ Cloud Core Router is an industrial-grade, high-performance rackmount router designed for ISPs, enterprise networks, data centres, fibre networks, and other demanding networking environments. Powered by a 16-core Tilera Tile-Gx16 processor running at 1.2GHz per core, it delivers substantial processing capability for complex routing and high-throughput network applications.

The CCR1016-12S-1S+ features 12 Gigabit SFP ports and one 10 Gigabit SFP+ port, making it particularly well suited to fibre-based network infrastructure. The interfaces connect directly to the CPU architecture, providing a powerful platform for routing large volumes of network traffic.

With 2GB RAM, 128MB NAND storage, RouterOS Level 6, redundant AC power supplies, and a 1U rackmount chassis, the CCR1016-12S-1S+ is built for professional network deployments where performance, fibre connectivity, and power redundancy are important.

Product Features

16-Core Tilera Processor

Powered by a Tilera Tile-Gx16 CPU with 16 cores operating at 1.2GHz per core, providing high processing capability for demanding routing workloads.

12 Gigabit SFP Ports

Features 12 × SFP interfaces for Gigabit fibre connectivity, making the router suitable for fibre distribution, ISP networks, enterprise backbones, and data centre applications.

10 Gigabit SFP+ Connectivity

Includes 1 × SFP+ interface supporting 10 Gigabit connectivity for high-speed uplinks, backbone connections, and other bandwidth-intensive network applications.

2GB RAM

Equipped with 2GB of built-in RAM to support RouterOS and demanding network configurations.

RouterOS Level 6

Runs MikroTik RouterOS with Level 6 licensing, providing extensive routing, firewall, VPN, QoS, bandwidth management, monitoring, and network administration capabilities.

Redundant Power Supplies

Features dual integrated AC power supplies, allowing power redundancy for professional installations where network availability is important.

1U Rackmount Design

The 1U rackmount chassis is designed for installation in standard network and server racks, making it suitable for data centres, server rooms, ISP facilities, and enterprise network environments.

Professional Fibre Networking

The combination of twelve SFP ports and a 10G SFP+ interface makes the CCR1016-12S-1S+ particularly suitable for fibre-centric network infrastructure.

Serial and USB Connectivity

Provides additional management and expansion connectivity through a serial interface and USB port.

RouterOS Network Management

Supports advanced RouterOS functionality for professional network administration, including routing protocols, firewalling, VPNs, traffic management, VLANs, monitoring, scripting, and other network services.

Product Specifications

• Product Type: Cloud Core Router
• Brand: MikroTik
• Model: CCR1016-12S-1S+
• CPU: Tilera Tile-Gx16
• CPU Cores: 16
• CPU Frequency:2GHz per core
• RAM: 2GB
• Storage: 128MB NAND
• Gigabit SFP Ports: 12
• 10 Gigabit SFP+ Ports: 1
• Ethernet Connectivity: RJ45 SFP copper module included
• Operating System: MikroTik RouterOS
• RouterOS License: Level 6
• Power Supplies: Dual Redundant AC Power Supplies
• Input Voltage: 100–240V AC
• Maximum Power Consumption: Approximately 44–48W depending on hardware revision/documentation
• Serial Interface: Yes
• USB: Yes
• Rackmount: 1U
• Dimensions: Approximately 443 × 197 × 44mm
• Operating Temperature: Approximately -20°C to +60°C, subject to hardware revision
• Installation: Indoor Rackmount
• Suitable For: ISPs, Data Centres, Enterprise Networks, Fibre Networks and High-Performance Routing
• Applications: Core Routing, Fibre Aggregation, Network Backbone, ISP Infrastructure, VPN, Firewalling, VLAN Routing and Bandwidth Management
• Included Accessories: Rackmount Ears, Power Cords and RJ45 SFP Copper Module
