Cisco CBS110-8T-D-UK 8-Port Unmanaged Gigabit Switch (Non-PoE)

The Cisco CBS110-8T-D-UK is a compact, unmanaged Gigabit Ethernet switch designed for small businesses, home offices, and workgroups that require reliable, high-speed network connectivity. Featuring eight Gigabit Ethernet ports, it delivers plug-and-play operation without the need for configuration, making it easy to expand wired networks. With wire-speed performance, energy-efficient technology, and a fanless design, the CBS110-8T-D-UK provides dependable and quiet networking for desktops, printers, IP cameras, network-attached storage (NAS), and other Ethernet-enabled devices.

Product Features

8 Gigabit Ethernet Ports

Provides eight 10/100/1000 Mbps RJ45 ports for high-speed wired connections to computers, printers, NAS devices, IP cameras, and other network equipment.

Plug-and-Play Operation

Requires no software installation or configuration, allowing devices to connect and communicate immediately after installation.

Wire-Speed Performance

Delivers non-blocking switching performance to ensure fast and reliable data transmission across all ports.

Fanless Silent Design

Operates without a cooling fan, providing completely silent performance for offices, retail environments, and home workspaces.

Energy-Efficient Technology

Supports IEEE 802.3az Energy Efficient Ethernet (EEE), automatically reducing power consumption during periods of low network activity.

Automatic MDI/MDIX Detection

Automatically detects cable type, eliminating the need for crossover cables and simplifying installation.

Quality of Service (QoS)

Supports IEEE 802.1p Quality of Service to prioritize time-sensitive traffic such as voice and video for improved network performance.

Durable Desktop Design

Features a compact desktop form factor with wall-mount capability, making it suitable for space-constrained installations.

Product Specifications

• Model: CBS110-8T-D-UK
• Product Type: Unmanaged Gigabit Ethernet Switch
• Series: Cisco Business 110 Series
• Ethernet Ports: 8 × 10/100/1000 Mbps Gigabit RJ45 Ports
• PoE Support: No
• Switching Capacity: 16 Gbps
• Forwarding Rate: 11.9 Mpps
• MAC Address Table: 8K Entries
• Packet Buffer: 2 Mbit
• Jumbo Frame Support: Up to 9,216 Bytes
• Quality of Service: IEEE 802.1p QoS
• Flow Control: IEEE 802.3x
• Energy Efficiency: IEEE 802.3az Energy Efficient Ethernet
• Auto MDI/MDIX: Supported
• Loop Detection: Supported
• Cable Diagnostics: Supported
• Management: Unmanaged (Plug-and-Play)
• Cooling: Fanless
• Power Input: External 100–240V AC Power Adapter
• Operating Temperature: 0°C to 50°C
• Dimensions: 160 × 104 × 30 mm
• Weight: Approximately 0.43 kg
• Mounting Options: Desktop or Wall Mount
• Ideal Applications: Small businesses, home offices, retail stores, classrooms, workgroups, and general Gigabit Ethernet network expansion.
