Security Door Bolt Lock

The Security Door Bolt Lock is a robust electronic locking solution designed to provide enhanced security for access control systems. Featuring a durable stainless steel bolt, fast locking response, and low-voltage DC operation, this electric bolt lock delivers reliable performance for residential, commercial, and industrial applications. It integrates seamlessly with biometric access control terminals, RFID card readers, keypads, video intercom systems, and door controllers, making it an ideal choice for secure electronic door locking.

Product Features

High-Security Electric Bolt Mechanism

The lock uses a solid stainless steel bolt that securely locks the door in place, providing excellent resistance against forced entry and unauthorized access.

Durable Stainless Steel Construction

Manufactured from high-quality stainless steel and reinforced metal components, the bolt lock offers exceptional durability, corrosion resistance, and reliable long-term performance.

Fast Locking and Unlocking Response

Designed for rapid electronic operation, the bolt extends and retracts quickly when triggered by an access control system, ensuring smooth and secure entry.

DC 12V Low Voltage Operation

Operates on a standard 12V DC power supply, delivering safe, energy-efficient performance while remaining compatible with most electronic access control installations.

Intelligent Time Delay Function

Many models support selectable delay settings, allowing the bolt to lock automatically after 0, 3, 6, or 9 seconds, providing added flexibility for different installation requirements.

Built-in Door Status Detection

Integrated sensors detect whether the door is properly aligned before engaging the locking bolt, reducing wear and preventing accidental locking when the door is not fully closed.

Wide Access Control Compatibility

Compatible with fingerprint readers, facial recognition terminals, RFID card readers, password keypads, exit buttons, electric strikes, magnetic locks, and video intercom systems.

Low Power Consumption

Designed for continuous operation with minimal power usage, making it suitable for offices, apartments, commercial buildings, and high-traffic entrances.

Easy Surface or Concealed Installation

Can be installed on wooden, metal, aluminium, and glass doors (with appropriate brackets), making it suitable for both new installations and system upgrades.

Ideal for Professional Access Control

Perfect for offices, apartment complexes, hotels, banks, hospitals, schools, warehouses, retail stores, factories, and government buildings requiring secure electronic door locking.

Product Specifications

• Product Type: Electric Security Door Bolt Lock
• Operating Voltage: DC 12V
• Operating Current: Approximately 900 mA (Start), 120 mA (Standby)
• Lock Type: Electric Bolt Lock
• Bolt Material: Solid Stainless Steel
• Faceplate Material: Stainless Steel
• Bolt Throw: Approximately 16 mm
• Holding Force: Up to 1,000 kg
• Time Delay: 0, 3, 6, or 9 Seconds (Model Dependent)
• Door Status Sensor: Yes
• Suitable Door Types: Wooden, Metal, Aluminium, Glass (with brackets)
• Operating Temperature: -10°C to +55°C
• Operating Humidity: 0%–90% RH
• Application: Access Control Systems, Biometric Door Entry, RFID Access Control, Video Intercom Systems, Commercial Buildings, Residential Properties, and Industrial Facilities
