JVA Z13 1 Zone Security Energizer 2.8 Joule

The JVA Z13 1 Zone Security Energizer 2.8 Joule is a professional-grade electric fence energizer engineered to provide reliable perimeter security for residential, commercial, industrial, and institutional properties. Designed for a single electric fence zone, it delivers 2.8 Joules of peak output energy while continuously monitoring the fence for tampering, short circuits, and open circuits. With a built-in battery charger, programmable operation, and advanced surge protection, the JVA Z13 is an ideal solution for modern perimeter security systems.

Product Features

Single Zone Fence Monitoring

Monitors one independent electric fence zone, providing accurate fault detection and alarm activation.

2.8 Joule Peak Output Energy

Delivers a powerful high-voltage, low-current pulse for effective perimeter protection.

High and Low Power Modes

Allows users to select the appropriate output level based on the security requirements of the installation.

Intelligent Fence Monitoring

Continuously detects wire cuts, short circuits, open circuits, and other fence faults for enhanced security.

Built-In Battery Charger

Includes an integrated charger for a compatible 12V backup battery, ensuring continued operation during power outages.

Alarm System Integration

Features programmable control inputs and switched outputs for easy integration with sirens, strobes, and security alarm systems.

Lightning and Surge Protection

Built-in protection helps safeguard the energizer from electrical surges and lightning damage.

Expandable Security System

Compatible with optional keypads and monitoring software, and can be networked with other JVA Z-Series energizers for larger installations.

Product Specifications

• Brand: JVA
• Model: Z13
• Product Type: Security Electric Fence Energizer
• Fence Zones: 1
• Peak Output Energy:8 Joules
• Power Modes: High and Low
• Power Supply: 16–18V AC via External Transformer
• Battery Backup: 12V 7Ah Rechargeable Battery Compatible (Battery Not Included)
• Built-In Battery Charger: Yes
• Control Inputs: 2
• Switched Outputs: 2 × 12V DC (Suitable for Siren and Strobe)
• Fence Monitoring: Short Circuit, Open Circuit, and Tamper Detection
• Gate Monitoring: Supported
• Protection: Built-In Lightning and Surge Protection
• Compliance: IEC 60335-2-76
• Applications: Residential Estates, Commercial Buildings, Industrial Facilities, Warehouses, Schools, Government Premises, and High-Security Perimeter Fencing
• Warranty: 3 Years (Lightning Damage Excluded)
