EZ640 Hammer Electric Fence Energizer Machine

The EZ640 Hammer Electric Fence Energizer Machine is a powerful single-zone electric fence energizer designed to provide dependable perimeter security for residential, commercial, agricultural, and industrial properties. Delivering 5 Joules of output energy with a maximum output voltage of 10kV, it is capable of powering electric fences up to 6km using 1.6mm fence wire under ideal conditions. The EZ640 features intelligent fence monitoring, battery backup, solar compatibility, gate monitoring, and built-in surge protection, making it a reliable solution for continuous electric fence protection.

Product Features

Powerful 5 Joule Output

Delivers 5 Joules of output energy with a maximum fence voltage of 10kV, providing effective protection against unauthorized access.

Single Zone Monitoring

Continuously monitors the fence return voltage and detects fence faults, voltage loss, and tampering for improved perimeter security.

Long Fence Coverage

Capable of powering up to 6km of 1.6mm fence wire under ideal installation conditions.

Battery Backup

Supports a built-in 12V backup battery to maintain fence operation during mains power failures.

Solar Compatible

Can be integrated with a solar charging system, making it suitable for remote or off-grid installations.

Gate Monitoring

Includes an auxiliary gate input that detects gate opening or tampering and triggers an alarm when required.

Siren and Strobe Outputs

Provides dedicated outputs for connecting external sirens and strobe lights for immediate audible and visual alarm notification.

Remote Control Option

Supports an optional remote control or keypad for convenient operation and system management.

Lightning and Surge Protection

Built-in lightning and power surge suppression protects the energizer from electrical damage and extends its service life.

Easy Installation

Compact, wall-mounted design allows for quick installation and straightforward maintenance.

Product Specifications

• Brand: Hammer
• Model: EZ640
• Product Type: Single-Zone Electric Fence Energizer
• Fence Zones: 1
• Output Energy: 5 Joules
• Stored Energy: 8 Joules
• Maximum Output Voltage: 10kV
• Maximum Fence Length: Up to 6km (Using 1.6mm Fence Wire)
• Power Supply: 220–240V AC
• Battery Backup: Yes
• Recommended Battery: 12V 7Ah Rechargeable Battery
• Backup Time: Up to 12 Hours
• Fence Monitoring: Return Voltage Monitoring
• Gate Monitoring: Yes
• Alarm Outputs: Siren and Strobe Outputs
• Remote Control Compatible: Yes
• Solar Compatible: Yes
• Lightning Protection: Built-In
• Surge Protection: Built-In
• Installation: Wall Mounted
• Applications: Residential Homes, Commercial Buildings, Industrial Facilities, Farms, Warehouses, Institutions, and High-Security Electric Fence Systems
