D-Link DGS-F1006P-E 250M 6-Port 1000Mbps Switch with 4 PoE Ports and 2 Uplink Ports

The D-Link DGS-F1006P-E is a compact unmanaged Gigabit PoE switch designed for small business networks, IP surveillance systems, wireless access points, and VoIP deployments. It features four Gigabit PoE+ ports and two dedicated Gigabit uplink ports, enabling both power and high-speed data transmission over a single Ethernet cable. With support for PoE transmission distances of up to 250 meters in Extend Mode, a total PoE power budget of 60W, and plug-and-play operation, the DGS-F1006P-E offers a reliable and cost-effective networking solution for small-scale installations. It also includes VLAN isolation, QoS optimization, PoE Auto Recovery, and 6KV surge protection for enhanced performance and network reliability.

Product Features

4 Gigabit PoE+ Ports

Equipped with four 10/100/1000 Mbps RJ45 ports supporting IEEE 802.3af and IEEE 802.3at PoE standards, allowing compatible devices to receive both power and data through a single Ethernet cable.

2 Dedicated Gigabit Uplink Ports

Includes two Gigabit uplink ports for connecting to routers, network video recorders (NVRs), servers, or additional switches without occupying PoE ports.

Long-Range PoE Transmission

Extend Mode supports PoE and data transmission over distances of up to 250 meters at 10 Mbps, making it ideal for long-distance IP camera installations.

60W Total PoE Power Budget

Provides a total PoE power budget of up to 60W, with each PoE port capable of delivering up to 30W to connected devices.

Plug-and-Play Installation

Requires no software configuration, allowing for quick deployment by simply connecting compatible network devices.

VLAN Isolation Mode

Supports port isolation to reduce broadcast traffic, improve network efficiency, and enhance security for surveillance networks.

Quality of Service (QoS)

Prioritizes video and voice traffic to ensure smooth performance for IP cameras, VoIP phones, and other latency-sensitive applications.

PoE Auto Recovery

Automatically detects and restarts unresponsive PoE-powered devices, minimizing downtime and reducing maintenance requirements.

6KV Surge Protection

Integrated surge protection safeguards the switch and connected equipment from electrical surges and lightning-related damage.

Fanless Compact Design

The silent fanless design ensures quiet operation and reliable performance in offices, retail stores, classrooms, and surveillance installations.

Product Specifications

• Model: D-Link DGS-F1006P-E
• Product Type: Unmanaged Gigabit PoE+ Switch
• Total Ports: 6
• PoE Ports: 4 × 10/100/1000 Mbps RJ45
• Uplink Ports: 2 × 10/100/1000 Mbps Gigabit RJ45
• PoE Standards: IEEE 802.3af and IEEE 802.3at
• Maximum PoE Output per Port: Up to 30W
• Total PoE Budget: 60W
• Maximum PoE Distance: Up to 250 meters (Extend Mode at 10 Mbps)
• Switching Capacity: 12 Gbps
• Packet Forwarding Rate: Up to 8.93 Mpps
• MAC Address Table: 2K Entries
• Transmission Method: Store-and-Forward
• Flow Control: IEEE 802.3x
• Auto Negotiation: Supported
• Auto MDI/MDIX: Supported on all ports
• Operating Modes: Standard, Extend, VLAN, QoS, PoE Auto Recovery
• Surge Protection: 6KV
• LED Indicators: Power, Link/Activity, PoE Status
• Operating Temperature: 0°C to 40°C
• Operating Humidity: 0% to 95% non-condensing
• Dimensions: 135 × 75 × 27 mm
• Installation: Desktop
• Power Supply: External Power Adapter
• Ideal Applications: IP surveillance systems, wireless access points, VoIP phones, retail stores, offices, schools, hotels, and small business networks.
