D-Link DGS-1210-52 52-Port Gigabit Smart Managed Switch (Non-PoE)

The D-Link DGS-1210-52 is a high-performance Layer 2+ Smart Managed Gigabit switch designed for medium and large business networks, enterprise environments, educational institutions, and data-intensive applications. It features forty-eight Gigabit Ethernet ports and four Gigabit RJ45/SFP combo uplink ports, providing flexible copper and fiber connectivity for network expansion. With advanced Layer 2+ management, static routing, robust security features, VLAN support, and an intuitive web-based management interface, the DGS-1210-52 delivers reliable, scalable, and cost-effective networking without Power over Ethernet (PoE).

Product Features

48 Gigabit Ethernet Ports

Equipped with forty-eight 10/100/1000 Mbps RJ45 ports, delivering high-speed Gigabit connectivity for workstations, servers, storage devices, and network infrastructure.

4 Gigabit RJ45/SFP Combo Uplink Ports

Features four combo uplink ports that support either Gigabit RJ45 or SFP fiber connections, providing flexible network expansion and long-distance connectivity.

Layer 2+ Smart Management

Supports advanced networking features including VLANs, Link Aggregation (LACP), Spanning Tree Protocol (STP, RSTP, MSTP), IGMP Snooping, and Static IPv4 Routing for efficient traffic management.

Comprehensive Security Features

Includes Access Control Lists (ACLs), IEEE 802.1X authentication, DHCP Server Screening, IP-MAC-Port Binding, Storm Control, and D-Link Safeguard Engine to protect the network against unauthorized access and malicious traffic.

Quality of Service (QoS)

Provides advanced QoS capabilities to prioritize voice, video, and mission-critical applications for consistent network performance.

Flexible Management Options

Supports web-based management, command-line interface (CLI), SNMP, and D-Link Network Assistant for simplified configuration, monitoring, and maintenance.

Energy-Efficient Operation

Supports IEEE 802.3az Energy Efficient Ethernet (EEE) and D-Link Green technology to reduce power consumption without compromising network performance.

Enterprise-Ready Design

Built for continuous operation with a durable rack-mountable chassis, making it suitable for business, education, and enterprise networking environments.

Product Specifications

• Model: DGS-1210-52
• Switch Type: Layer 2+ Smart Managed Gigabit Switch (Non-PoE)
• Ethernet Ports: 48 × 10/100/1000 Mbps Gigabit RJ45 Ports
• Uplink Ports: 4 × Gigabit RJ45/SFP Combo Ports
• PoE Support: No
• Switching Capacity: 104 Gbps
• Packet Forwarding Rate: 77.4 Mpps
• MAC Address Table: 8K Entries
• Packet Buffer Memory: 12 Mbits
• Jumbo Frame Support: Up to 9 KB
• VLAN Support: IEEE 802.1Q VLAN, Voice VLAN, Surveillance VLAN
• Link Aggregation: IEEE 802.3ad LACP
• Spanning Tree Protocol: STP, RSTP, MSTP
• Static Routing: IPv4 Static Routing
• Quality of Service: IEEE 802.1p QoS
• Security Features: ACL, IEEE 802.1X Authentication, DHCP Server Screening, IP-MAC-Port Binding, Storm Control
• Management Interfaces: Web GUI, CLI, SNMP, D-Link Network Assistant
• Energy Efficiency: IEEE 802.3az Energy Efficient Ethernet
• Console Port: Supported
• Power Input: 100–240V AC, 50/60 Hz
• Maximum Power Consumption: 34.85W
• Cooling: Smart Fan
• Operating Temperature: -5°C to 50°C
• Dimensions: 440 × 210 × 44 mm
• Weight: 3.46 kg
• Mounting Options: Rack Mount
• Ideal Applications: Enterprise networks, educational institutions, offices, data centers, server rooms, and medium to large business environments.
