D-Link DGS-F1210-26PS-E 24-Port Managed Gigabit PoE Switch

The D-Link DGS-F1210-26PS-E is a Layer 2 smart managed Gigabit PoE switch designed to deliver reliable, high-performance networking for businesses, surveillance systems, educational institutions, and enterprise environments. Equipped with 24 Gigabit PoE ports and 2 Gigabit SFP uplink ports, the switch provides high-speed connectivity while supplying power to compatible devices such as IP cameras, wireless access points, VoIP phones, and other network devices through a single Ethernet cable.

With an intelligent management interface, advanced Layer 2 features, and long-range PoE support of up to 250 meters in Extend Mode, the DGS-F1210-26PS-E offers a flexible and scalable networking solution. Features such as VLAN, Quality of Service (QoS), Link Aggregation, Access Control Lists (ACL), PoE Watchdog, and Spanning Tree Protocol (STP) ensure efficient traffic management, enhanced security, and dependable network performance for demanding applications.

Product Features

24 Gigabit PoE Ports

Provides 24 × 10/100/1000Mbps RJ45 PoE ports for high-speed data transmission and power delivery to compatible network devices.

2 Gigabit SFP Uplink Ports

Includes two dedicated Gigabit SFP uplink ports for long-distance fiber connectivity and network expansion.

Smart Layer 2 Management

Supports advanced Layer 2 management features including VLAN, QoS, Link Aggregation, Port Mirroring, IGMP Snooping, and Access Control Lists (ACL).

Long-Range PoE Support

Supports PoE transmission distances of up to 250 meters in Extend Mode, making it ideal for IP surveillance deployments.

IEEE 802.3af/at PoE Support

Complies with IEEE 802.3af and IEEE 802.3at standards, delivering up to 30W of power per PoE port.

Intelligent PoE Management

Features PoE Watchdog to automatically detect and restart unresponsive powered devices, reducing downtime.

Advanced Network Security

Includes 802.1X authentication, ACL, DHCP Snooping, and other security features to protect network resources.

Link Aggregation

Supports IEEE 802.3ad Link Aggregation Control Protocol (LACP) to increase bandwidth and provide network redundancy.

Rack-Mountable Metal Chassis

Built with a durable metal enclosure suitable for rack installation in professional networking environments.

Easy Management

Supports web-based management, SNMP, Telnet, and SSH for simple configuration, monitoring, and maintenance.

Product Specifications

• Brand: D-Link
• Model: DGS-F1210-26PS-E
• Product Type: Layer 2 Smart Managed Gigabit PoE Switch
• Ethernet Ports: 24 × 10/100/1000Mbps RJ45 PoE Ports
• Uplink Ports: 2 × Gigabit SFP Ports
• Console Port: 1 × RJ45 Console Port
• PoE Standards: IEEE 802.3af/at
• Maximum PoE Output Per Port: Up to 30W
• Total PoE Power Budget: 230W
• Switching Capacity: 52Gbps
• Packet Forwarding Rate: 38.7Mpps
• MAC Address Table: 8K Entries
• VLAN Support: Yes
• Quality of Service (QoS): Supported
• Link Aggregation: IEEE 802.3ad LACP
• Access Control List (ACL): Supported
• 1X Authentication: Supported
• IGMP Snooping: Supported
• Spanning Tree Protocol: STP, RSTP, MSTP
• PoE Watchdog: Supported
• Extend Mode: Up to 250m PoE Transmission
• Surge Protection: 6kV
• Management Interfaces: Web GUI, SNMP, Telnet, SSH
• Mounting: Rack Mountable
• Power Supply: Internal AC Power Supply (100–240V AC, 50/60Hz)
• Operating Temperature: 0°C to 40°C
• Dimensions: 440 × 180 × 44 mm
• Weight: Approximately 3.0 kg
• Chassis Material: Metal

• Color: Black
