MikroTik RB951Ui-2HnD 2.4GHz Wireless Access Point with 5 Ethernet Ports

The MikroTik RB951Ui-2HnD is a compact 2.4GHz wireless access point and SOHO router designed for home, small office, and branch network deployments. It features five 10/100 Ethernet ports, a built-in 2.4GHz 802.11b/g/n wireless radio, a 600MHz processor, and 64MB of RAM for handling routing, wireless networking, and network management tasks. The device includes one Ethernet port with passive PoE output for powering a compatible external device, while RouterOS provides advanced features such as firewall management, NAT, DHCP, bandwidth control, VLAN support, VPN functionality, and routing. Its compact desktop enclosure and integrated wireless antennas make it a practical all-in-one solution for smaller wired and wireless networks.

Product Features

2.4GHz 802.11n Wireless Networking

The RB951Ui-2HnD provides 2.4GHz wireless connectivity using the 802.11b/g/n standards, offering reliable wireless access for compatible computers, smartphones, tablets, IoT devices, and other network equipment.

Five Fast Ethernet Ports

Five 10/100 Ethernet ports provide wired network connectivity for computers, switches, printers, access points, IP cameras, and other Ethernet-enabled devices.

Passive PoE Output

Ethernet port 5 provides passive PoE output, allowing the router to power a compatible external device through an Ethernet cable. The connected device must support the appropriate passive PoE voltage and power requirements.

600MHz Processor

The 600MHz CPU provides the processing capability required for routing, firewall, wireless management, bandwidth control, and other RouterOS functions.

RouterOS Operating System

MikroTik RouterOS provides extensive network-management functionality, including routing, firewall policies, NAT, DHCP, VLANs, VPN, bandwidth management, and wireless configuration.

Advanced Firewall and Routing

The RB951Ui-2HnD can be configured for advanced routing and firewall policies, allowing administrators to manage network traffic and control access between connected devices and networks.

Built-In Wireless Antennas

Integrated antennas provide a clean installation without requiring external antenna connections, making the device suitable for desktop and small-office deployments.

Compact Design

The compact enclosure is designed for convenient placement in homes, offices, and other locations where a dedicated wireless router and wired network ports are required.

Product Specifications

• Brand: MikroTik
• Product Series: RouterBOARD
• Model: RB951Ui-2HnD
• Product Type: Wireless access point and router
• Wireless Standard: IEEE 802.11b/g/n
• Wireless Frequency: 2.4GHz
• Wireless Data Rate: Up to 300Mbps
• Wireless MIMO: 2×2
• Ethernet Ports: 5 x 10/100 Mbps Fast Ethernet
• PoE Input: Passive PoE supported
• PoE Output: Passive PoE output on Ethernet port 5
• PoE Output Voltage: Same as input voltage
• Processor: Qualcomm Atheros 600MHz
• CPU Architecture: MIPSBE
• CPU Cores: 1
• System Memory: 64MB RAM
• Storage: 16MB flash
• Storage Type: NAND
• Operating System: MikroTik RouterOS
• RouterOS License: Level 4
• Antenna Type: Integrated dual-chain antenna
• Antenna Gain: 2.5 dBi
• Wireless Security: WPA/WPA2 and supported RouterOS wireless security features
• Routing: Static routing and RouterOS-supported dynamic routing features
• Firewall: Stateful firewall
• NAT: Supported
• DHCP: DHCP server and client
• VLAN: Supported
• VPN: Supported through RouterOS
• Quality of Service: Supported
• Management: Web interface, command line, WinBox, and other RouterOS management tools
• Power Input: DC jack and passive PoE
• DC Input Voltage: 8 to 30V DC
• Maximum Power Consumption: Approximately 7W
• Operating Temperature: -20 to 50°C (-4 to 122°F)
• Dimensions: Approximately 113 x 138 x 29 mm
• Installation: Desktop or wall mounting
• Status Indicators: Power, Ethernet, and wireless LEDs

• Reset: Physical reset button
