ZKTeco FHT2400D Dual-Lane Full Height Turnstile with Optional Access Control Reader

The ZKTeco FHT2400D is a dual-lane full-height turnstile designed to provide maximum pedestrian security for high-security facilities. Constructed from durable SUS304 stainless steel, it offers reliable bidirectional access control while preventing unauthorized entry, tailgating, and forced access. The turnstile supports optional RFID, fingerprint, or other compatible access control readers, making it an ideal solution for industrial sites, government facilities, correctional institutions, stadiums, data centers, warehouses, and corporate campuses.

Product Features

Dual-Lane Design

Provides two independent pedestrian lanes, allowing higher throughput while maintaining strict access control.

Full-Height Security

The full-height rotating barrier prevents climbing and tailgating, ensuring only authorized individuals gain entry.

Optional Access Control Readers

Supports integration with RFID card readers, fingerprint readers, facial recognition terminals, and other compatible access control devices.

Heavy-Duty Stainless Steel Construction

Manufactured from SUS304 stainless steel for superior durability, corrosion resistance, and long-term outdoor performance.

Bi-Directional Operation

Supports controlled entry and exit with configurable one-way or two-way access depending on site requirements.

High Throughput

Designed to efficiently handle high pedestrian traffic while maintaining secure access control.

Emergency Release Function

Includes an emergency mode that allows safe evacuation during power failures or emergency situations.

LED Status Indicators

Integrated LED indicators clearly display lane availability and access status for improved user guidance.

Indoor and Outdoor Installation

Engineered for reliable operation in both indoor and outdoor environments.

Seamless Security Integration

Compatible with access control systems, time attendance terminals, visitor management systems, and building security platforms.

Product Specifications

• Brand: ZKTeco
• Model: FHT2400D
• Product Type: Dual-Lane Full Height Turnstile
• Operation: Semi-Automatic
• Access Control: Optional RFID, Fingerprint, Facial Recognition, and Other Compatible Readers
• Lane Width: 580 mm
• Throughput: Up to 20 persons/minute (RFID), up to 15 persons/minute (Fingerprint)
• Barrier Movement: Rotating
• Direction: Bi-Directional
• Cabinet Material: SUS304 Stainless Steel
• Barrier Material: SUS304 Stainless Steel
• Power Supply: AC 110–220 V, 50/60 Hz
• Working Environment: Indoor and Outdoor
• Ingress Protection: IP54
• Operating Temperature: -28°C to +60°C
• Operating Humidity: 0%–95% RH
• Emergency Mode: Supported
• LED Indicator: Supported
• Security Level: High
• MCBF: 1,000,000 Cycles
• Dimensions: 2018 × 1324 × 2220 mm
• Applications: Industrial Facilities, Government Buildings, Data Centers, Stadiums, Warehouses, Manufacturing Plants, Airports, Correctional Facilities, Office Complexes, Universities, and High-Security Perimeters.
