UGREEN USB-C 3.1 Gen 2 2.5-Inch HDD/SSD Enclosure Aluminum UG 70498

The UGREEN USB-C HDD Enclosure UG 70498 is a high-speed external storage enclosure designed for 2.5-inch SATA HDDs and SSDs. Featuring a USB-C 3.1 Gen 2 interface, SATA III support, UASP protocol, aluminium alloy housing, and support for drives up to 6TB, it provides a convenient way to convert an internal hard drive or SSD into portable external storage.

Its durable aluminium construction provides effective heat dissipation, while plug-and-play operation makes it ideal for data backup, storage expansion, file transfers, drive cloning, and reusing existing 2.5-inch SATA drives.

Product Features

High-Speed USB-C 3.1 Gen 2 Interface

The USB-C 3.1 Gen 2 interface supports high-speed connectivity, providing fast and efficient access to files stored on compatible SATA HDDs and SSDs.

SATA III Support

The enclosure supports SATA III with speeds up to 6Gbps, allowing compatible SATA SSDs to deliver significantly faster performance than conventional mechanical hard drives.

UASP Protocol Support

Built-in UASP support improves data transfer efficiency when used with compatible drives, operating systems, and USB interfaces, making the enclosure suitable for transferring large files and regular backup tasks.

Supports 2.5-Inch HDDs and SSDs

Designed for standard 2.5-inch SATA I, SATA II, and SATA III HDDs and SSDs, including drives with common 7mm and 9.5mm form factors.

Up to 6TB Drive Capacity

The enclosure supports compatible storage drives with capacities of up to 6TB, providing plenty of room for documents, photos, videos, applications, backups, and other files.

Durable Aluminium Alloy Housing

The aluminium alloy construction provides a strong exterior while helping dissipate heat generated by the installed drive during operation.

Automatic Sleep Mode

An automatic sleep function helps reduce unnecessary drive activity during periods of inactivity, helping conserve power and reduce continuous operation of the installed drive.

LED Status Indicator

The integrated LED indicator provides a convenient visual indication of the enclosure’s operating and drive activity status.

USB Powered Design

Power is supplied through the USB connection, eliminating the need for a separate external power adapter during normal operation with compatible 2.5-inch drives.

Plug-and-Play Operation

The enclosure provides straightforward installation and operation, allowing a compatible SATA drive to be converted into external storage without complicated configuration.

Product Specifications

• Brand: UGREEN
• Product Code: UG 70498
• Product Type: HDD/SSD Enclosure
• Drive Form Factor:5 Inch
• Supported Drives: SATA HDD and SATA SSD
• SATA Compatibility: SATA I, SATA II and SATA III
• External Interface: USB-C 3.1 Gen 2
• SATA III Speed: Up to 6Gbps
• USB Interface Bandwidth: Up to 10Gbps
• Maximum Drive Capacity: Up to 6TB
• Supported Drive Thickness: 7mm and 9.5mm
• Protocol: UASP
• Controller Chip: ASM235CM
• Material: Aluminium Alloy
• Power Supply: USB Powered
• LED Indicator: Yes
• Automatic Sleep Mode: Supported
• Hot Swap: Supported
• Cable Length: Approximately 50cm
• Dimensions: Approximately 133 × 82 × 15mm
• Application: External Storage, Data Backup, File Transfer and Storage Expansion
