Ubiquiti Rocket AC airMAX ac BaseStation R5AC-LITE

The Ubiquiti Rocket AC airMAX ac BaseStation R5AC-LITE is a 5 GHz outdoor wireless base station designed for point-to-point and point-to-multipoint network deployments. It uses airMAX ac technology to provide high-capacity wireless connectivity for broadband distribution, backhaul links, WISP networks, rural connectivity, and outdoor network expansion. The compact design supports external sector and dish antennas, while airMAX TDMA technology helps improve network efficiency and performance when serving multiple remote stations.

Product Features

airMAX ac Technology

Uses Ubiquiti airMAX ac technology to provide improved wireless capacity, efficiency, and performance for outdoor broadband deployments.

5 GHz Wireless Operation

Operates in the 5 GHz frequency range, providing suitable spectrum for long-distance wireless links and outdoor network infrastructure.

Point-to-Multipoint Connectivity

Designed to work with compatible sector antennas for connecting multiple subscriber stations from a central base station.

Point-to-Point Backhaul

Can also be paired with compatible directional antennas for high-capacity point-to-point wireless links.

airMAX TDMA Protocol

airMAX TDMA technology coordinates client transmissions to reduce interference and improve network efficiency in multi-client deployments.

External Antenna Support

The Rocket AC Lite is designed to work with compatible external antennas, allowing network operators to select antenna coverage and gain according to the installation.

Outdoor Deployment

The rugged enclosure is designed for outdoor installations and includes protection against changing environmental conditions.

Gigabit Ethernet

Provides a Gigabit Ethernet interface for high-speed wired network connectivity and PoE power.

Product Specifications

• Brand: Ubiquiti
• Product line: airMAX
• Model: R5AC-LITE
• Product type: Outdoor 5 GHz wireless base station
• Wireless technology: airMAX ac
• Frequency range: 5 GHz
• Wireless mode: Point-to-point and point-to-multipoint
• Antenna: External antenna required
• Antenna connector: RP-SMA
• Ethernet interface: 1 x Gigabit Ethernet
• Ethernet speed: 10/100/1000 Mbps
• Wireless protocol: airMAX TDMA
• Management: Web-based management interface
• Power method: 24 V passive PoE
• Outdoor deployment: Yes
• Enclosure: Weather-resistant outdoor housing
• Mounting: Pole mounting
• Applications: WISP networks, wireless broadband, rural internet, outdoor backhaul, point-to-point links, point-to-multipoint networks, and network expansion
• Recommended use: Outdoor wireless infrastructure and high-capacity 5 GHz network deployments
