TP-Link EAP225-Outdoor AC1200 Wireless MU-MIMO Gigabit Outdoor Access Point

The TP-Link EAP225-Outdoor AC1200 Access Point is a professional outdoor wireless networking solution designed to deliver reliable and high-speed WiFi coverage in areas such as hotels, campuses, offices, resorts, gardens, and business environments. Featuring AC1200 dual-band WiFi technology, MU-MIMO support, high-gain antennas, and a durable weatherproof design, it provides stable wireless performance for multiple connected devices. With Gigabit Ethernet connectivity, Power over Ethernet support, seamless roaming, Omada Mesh technology, and centralized network management, the EAP225-Outdoor offers flexible installation and efficient control for expanding wireless networks.

Product Features

AC1200 Dual-Band WiFi Performance

Delivers combined wireless speeds of up to 1200Mbps, providing reliable connectivity for browsing, video streaming, online meetings, cloud applications, and other network activities.

Dual-Band Wireless Connectivity

Supports both 2.4GHz and 5GHz frequency bands, allowing devices to connect on the most suitable frequency for improved performance and reduced interference.

MU-MIMO Technology

Enables simultaneous communication with multiple devices, improving network efficiency and reducing congestion in environments with many users.

Weatherproof Outdoor Design

Built with an IP65-rated weather-resistant enclosure that protects the access point from dust and water, making it suitable for outdoor installations.

Long-Range Wireless Coverage

Equipped with high-power antennas to provide extended WiFi coverage across outdoor spaces and large areas.

Gigabit Ethernet Connectivity

Features a Gigabit Ethernet port for fast wired connections and efficient data transfer between the access point and network infrastructure.

Power over Ethernet Support

Supports PoE connectivity, allowing power and network data transmission through a single Ethernet cable for easier installation.

Omada SDN Centralized Management

Supports centralized management through the Omada platform, enabling easy configuration, monitoring, and control of multiple network devices.

Seamless Roaming Support

Provides smooth wireless transitions between access points, helping maintain stable connections for users moving around a network area.

Omada Mesh Support

Allows wireless expansion of network coverage without requiring additional wired connections between access points.

Flexible Mounting Options

Supports wall and pole mounting, making it suitable for various outdoor deployment locations.

Product Specifications

• Brand: TP-Link
• Product Type: Outdoor Wireless Access Point
• Model: EAP225-Outdoor
• WiFi Standard: IEEE 802.11a/b/g/n/ac
• WiFi Generation: AC1200 WiFi 5
• Wireless Speed: Up to 1200Mbps
• 4GHz Speed: Up to 300Mbps
• 5GHz Speed: Up to 867Mbps
• Frequency Bands: Dual Band (2.4GHz and 5GHz)
• Antennas: 2 × 3dBi 2.4GHz Antennas and 2 × 4dBi 5GHz Antennas
• Wireless Technologies: MU-MIMO, Beamforming, Band Steering, Airtime Fairness, Load Balancing
• Ethernet Port: 1 × Gigabit Ethernet Port
• PoE Support: 802.3af PoE and 24V Passive PoE
• Weather Protection Rating: IP65
• Lightning Protection: 4KV
• ESD Protection: 15KV
• Management Platform: Omada SDN
• Management Options: Hardware Controller, Software Controller, Cloud Controller, Mobile App
• Wireless Security: WPA/WPA2 Encryption, MAC Filtering, Wireless Isolation, VLAN Support, Captive Portal
• Mounting Options: Wall Mount and Pole Mount
• Maximum Client Capacity: 220+
• Dimensions: 215 × 46 × 27 mm
• Power Consumption: Up to 10.5W
• Operating Temperature: -30°C to 70°C
• Storage Temperature: -40°C to 70°C
• Compatible Environments: Outdoor Areas, Hotels, Offices, Schools, Resorts, Campuses, and Business Networks
• Package Contents: TP-Link EAP225-Outdoor Access Point, PoE Injector, Power Cable, Mounting Kit, Installation Guide

• Certifications: FCC, RoHS
