The DKVM-CB Keyboard, Video, and Mouse (KVM) cable

Product Features

• 4 KVM Ports.
• Allows Control of 4 USB-style PCs From a Single Keyboard, Mouse, and monitor.
• Supports VGA, SVGA & Multisync monitors.
• Supports Video Resolution 2048 x 1536 (Bandwidth Up to 400MHz).
• Supports USB Keyboard and mouse.
• Keyboard & Mouse Emulation for Error-Free Boot-Up.
• Supports Microsoft IntelliMouse & Microsoft IntelliMouse Explorer.
• PC Selection Via Push Button or Hot Keys.
• Audible Feedback When Switching.
• Auto Scan Mode.
• LED Indicator for Each PC.
• Auto Recall of CAPS LOCK, NUM.
• LOCK & SCROLL LOCK Status for Each PC.
• No Driver Required
• Bus Power, No AC Power Adapter Required

Technical Specifications

Connectors to Computers

• 4 DB-15 HDDB video connectors (to Computers’ monitor ports).
• 4 USB 2.0 Type B connectors (to computers’ USB ports).

Connectors to Console computer

• DB-15 HDDB video connector (to console monitor).
• USB Type A connector (to console USB keyboard) computer.
• USB connector (to console USB mouse).

Computer Selection keyboard
(Manually switching back and forth among 4 computers)

• Through push button 10 seconds.
• Through hotkeys.
• Switching confirmation: buzzer sound.

Hot Key Menu Functions

• Scroll Lock + Scroll Lock + 1: Switch to computer 1.
• Scroll Lock + Scroll Lock + 2: Switch to computer 2.
• Scroll Lock + Scroll Lock + 3: Switch to computer 3.
• Scroll Lock + Scroll Lock + 4: Switch to computer 4.
• Scroll Lock + Scroll Lock + –>: switch to the next computer.
• Scroll Lock + Scroll Lock + <–: switch to the previous computer.
• Scroll Lock + Scroll Lock + B: beeper ON/OFF.
• Scroll Lock + Scroll Lock + M: reset mouse and keyboard.
• Scroll Lock + Scroll Lock + S: auto-scan mode every 10 seconds.

Diagnostic LEDs

• 4 port LEDs for 4 connected computers.

Physical & Environmental
Power Consumption

• 5V 70mA

Power Supply

• Directly from the connected computer’s USB port, no external power adapter is required.

Dimensions

• 178 (L) x 105(W) x 30.5(H) mm.

Weight

• 275 grams

Emission (EMI)

• FCC Class B
• CE
• C-Tick

O.S. Support

• Microsoft Windows 98SE, ME, NT, 2000, XP, NT 2003.
• Linux Red Hat.

Box Includes

• DKVM-4U switch.
• 2 sets of 1.8 m KVM cables (each includes 1 video cable, 1 USB 2.0 cable).
• Quick Installation Guide.

Optional KVM Cables
(Each includes 1 video cable and 1 USB 2.0 cable)

• DKVM-CU 1.8 m (6 ft).
• DKVM-CU3 3 m (10 f t).
• DKVM-CU5 4.5 m (15 ft).
