Key Features

• 1 Megapixel High-Performance CMOS: Capture high-quality video with a 1MP CMOS image sensor, delivering clear and detailed footage.
• 720P Analog HD Output: Supports up to 720p resolution for sharp, high-definition video output.
• True Day/Night Functionality: Equipped with an IR-Cut Filter (ICR) for clear images in both daylight and low-light conditions.
• Digital Noise Reduction (DNR) & Smart IR: Reduces noise in low-light conditions and optimizes IR illumination for improved night vision.
• 20m IR Distance: Infrared night vision reaches up to 20 meters (66 feet), ensuring visibility even in complete darkness.
• IP66 Weatherproof Rating: Designed to withstand harsh weather conditions for reliable outdoor use.

Image Sensor

• Type: 1 Megapixel CMOS Image Sensor
• Effective Pixels: 1296(H) x 732(V)
• Signal System: Supports both PAL and NTSC standards
• Minimum Illumination:
  • 0.01 Lux @ F1.2 with AGC ON
  • 0 Lux with IR (infrared) active

Shutter Speed

• Range: 1/25 (1/30) seconds to 1/50,000 seconds for capturing fast-moving objects.

Lens Options

• Focal Length: Available in 2.8mm, 3.6mm, or 6mm
  • 2.8mm Lens: 92° field of view for wide-angle coverage
  • 3.6mm Lens: 70.9° field of view, ideal for mid-range monitoring
  • 6mm Lens: 56.7° field of view for detailed distant viewing
• Mount Type: M12 Lens Mount for secure fitting

Day & Night Mode

• IR-Cut Filter Removal (ICR): Automatically switches between color and black-and-white video based on lighting conditions.

Angle Adjustment

• Pan: 0° to 360°
• Tilt: 0° to 180°
• Rotation: 0° to 360°
• Adjustable Installation: Allows easy configuration for optimal camera positioning.

Video Specifications

• Frame Rate: 720p at 25fps (PAL) or 30fps (NTSC) for smooth video playback.
• HD Video Output: 1 analog HD output, compatible with standard DVRs.
• S/N Ratio: Greater than 62dB for clear video quality with minimal interference.

General Specifications

• Operating Temperature: -40°C to 60°C (-40°F to 140°F)
• Operating Humidity: 90% or less (non-condensing)
• Power Supply: 12V DC ±15% for stable operation
• Power Consumption: Maximum 4W for efficient energy use.
• Protection Level: IP66-rated enclosure, suitable for outdoor environments.
• IR Range: Night vision capability up to 20 meters (66 feet)
• Dimensions: 70 mm diameter x 149.5 mm length (2.76″ x 5.89″)
• Weight: 300 grams
