Fanvil X6U Enterprise IP Phone

The Fanvil X6U is a high-end enterprise IP phone engineered for busy professionals and call-intensive environments. Boasting a striking set of three color displays, up to 20 SIP lines, integrated enterprise-grade audio, and built-in Bluetooth, it delivers exceptional productivity and versatility. With PoE, dual Gigabit ports, optional Wi-Fi, EHS headset support, and advanced codecs like Opus and G.722, this device offers unified communication with crystal-clear sound and seamless connectivity.

Product Features

Triple-Color Screens & DSS Expansion

Features a 4.3″ main screen plus two 2.4″ side screens, supporting up to 60 programmable DSS keys with LED indicators to enable rapid line access and monitoring.

Multi-Line & Conference Capability

Manages up to 20 SIP accounts and supports multi-party conferencing—3-way in initial versions and up to 6-way in updated models.

Enterprise HD Audio

Equipped with Harman speaker and wideband Opus and G.722 codecs, alongside full-duplex speakerphone, echo cancellation, noise reduction, and dynamic jitter buffering.

Bluetooth, Wi‑Fi & EHS Support

Offers built-in Bluetooth (2.1/4.2), USB port for optional Wi‑Fi dongle or call recording, and EHS compatibility for wireless headsets.

Network & Power Flexibility

Includes dual Gigabit Ethernet with PoE (802.3af), IPv4/IPv6, VPN support, 802.1x authentication, VLAN, QoS, and provision protocols like TR‑069 and SNMP.

Secure & Manageable

Supports SRTP/TLS, HTTPS, SSH, with web-based provisioning, remote auto-provisioning, and TR‑069 for scalable deployment.

Product Specifications

• SIP Lines Supported: Up to 20

• Displays:

  • Main: 4.3″ color (480×272)

  • Two side: 2.4″ color each, for DSS

• DSS Keys: Up to 60 via side displays (12 physical keys)

• Audio Codecs: Opus, G.722, G.711(A/µ), G.729AB, G.726, iLBC

• Speakerphone Features: Full-duplex, AEC, VAD, CNG, BNE, NR, PLC

• Conference: 3-way (v1); 6-way (v2)

• Ethernet Ports: Dual Gigabit (10/100/1000 Mbps), PoE

• Wireless: Built-in Bluetooth; USB for Wi‑Fi dongle or call recording

• Headset Support: RJ9 + EHS for Plantronics, Jabra, Sennheiser

• Video Codec: H.264 VGA QCIF/CIF (for door‑phone/camera)

• Security: SRTP/TLS, HTTPS, SSH, 802.1x, VLAN, VPN (L2TP/OpenVPN), QoS

• Provisioning: Web UI, auto-provision, TR‑069, SNMP, LDAP/XML phonebook

• Power Options: PoE or DC 5 V/1 A adapter

• Physical: 273 × 209 × 118 mm, ~1.6 kg; desk or wall mountable

• Operating Conditions: 0–45 °C, 10–95 % RH

• Compliance: IPv4/IPv6, SIP v1/v2, DTMF RFCs, PoE IEEE 802.3af, 802.1x, CE/regionals
