EVI 2000VA 1800W Rack Mount Online UPS with Double Conversion – EP-UPS2000UC13OR

The EVI 2000VA 1800W Rack Mount Online UPS is a high-performance, true double conversion power backup solution designed for critical IT systems, servers, data networks, and sensitive electronic equipment. Built to deliver continuous, clean power with zero transfer time, this UPS provides maximum protection against voltage fluctuations, outages, and power disturbances. With an output power factor of 1.0, a wide input voltage range, and intelligent battery management, it ensures efficiency, reliability, and long-term performance. This model features a rotating LCD display, supports lithium battery systems, and includes communication options for advanced power monitoring and control.

Product Features

Online Double Conversion Topology

Provides uninterrupted, pure sine wave power with zero transfer time, ensuring consistent voltage and frequency. Protects sensitive devices from surges, spikes, and brownouts, making it ideal for mission-critical applications.

2000VA / 1800W Output with Power Factor 1.0

Delivers the full 1800W of real power to connected equipment, maximizing usable capacity and supporting modern high-efficiency IT infrastructure.

Wide Input Voltage Range

Accepts input from 110V to 300V AC, reducing battery usage during voltage fluctuations and ensuring compatibility with unstable power sources or generators.

Input Power Factor Correction

The high input power factor of 0.99 reduces electrical losses and improves overall efficiency, lowering energy costs and minimizing the load on electrical circuits.

Selectable Output Voltage

Output voltage is configurable to 200V, 208V, 220V, 230V, or 240V AC, supporting a wide range of regional and equipment requirements.

Frequency Converter Mode

Offers the ability to convert between 50Hz and 60Hz output, making it suitable for global deployments and frequency-sensitive applications.

Adjustable Charging Current

Supports optional charging current of either 1A or 2A. The 2A mode is optimized for systems using multiple battery banks, enabling faster recharge cycles and extended runtimes.

Smart Battery Charging Design

Intelligent charging extends battery life and improves performance. Compatible with both sealed lead-acid and lithium batteries, and integrates with battery management systems (BMS) for enhanced monitoring.

ECO Mode Operation

Supports high-efficiency ECO mode to reduce power consumption and heat output under stable power conditions, improving overall energy efficiency.

Emergency Power Off (EPO)

Includes an EPO function for emergency shutdowns, enabling quick power cut-off in critical safety situations or during system maintenance.

Low Priority Load Disconnection

Automatically disconnects non-critical loads during extended outages, conserving battery power for high-priority systems and increasing total runtime.

Rotating LCD Display

User-friendly LCD interface provides real-time system information such as input/output voltage, battery level, load status, and alarm notifications. The display can rotate for convenient rack or tower mounting.

Generator Compatibility

Fully compatible with generator power, enabling seamless operation during extended outages or in off-grid environments.

Versatile Communication Ports

Equipped with USB and RS232 ports for system monitoring. Supports optional SNMP card for advanced remote management via network integration.

8 IEC C13 Output Sockets

Features eight IEC C13 outlets, offering secure and standardized connections for servers, switches, and other critical equipment.

Product Specifications

• Capacity: 2000VA / 1800W
• UPS Type: Online Double Conversion
• Output Power Factor: 1.0
• Input Voltage Range: 110V – 300V AC
• Input Frequency: 40Hz – 70Hz (Auto sensing)
• Input Power Factor: ≥ 0.99 with PFC
• Output Voltage (Selectable): 200V, 208V, 220V, 230V, 240V AC
• Output Frequency: 50Hz / 60Hz (Configurable)
• Output Waveform: Pure Sine Wave
• Transfer Time: 0 ms
• Charging Current: Selectable 1A or 2A
• Battery Type: Sealed Lead-Acid and Lithium (BMS supported)
• Battery Management: Smart charging system with optimized performance
• ECO Mode: Supported
• Emergency Power Off (EPO): Yes
• Generator Compatibility: Yes
• Load Segmentation: Low priority load disconnection
• Communication Ports: USB, RS232, Optional SNMP card
• Display: Rotating LCD Display (Input/Output, Load, Battery, Status)
• Output Sockets: 8 × IEC C13
• Operating Temperature: 0°C to 40°C
• Relative Humidity: 0% – 90% non-condensing
• Warranty: 2 years on UPS, 1 year on battery
• Model Number: EP-UPS2000UC13OR
