Eaton 10KVA / 8kW 9E10KI Online Tower UPS
Eaton 10KVA / 8kW 9E10KI Online Tower UPS from the leading Eaton dealer in Nairobi Kenya, buy Eaton 10KVA / 8kW 9E10KI Online Tower UPS and have it delivered.
Eaton 9E is online double-conversion power protection at an affordable price with compact yet robust construction. This UPS is an ideal choice for industrial, medical, and information technology (IT) applications and telecommunications.
Product Specifications
| General | |
| Topology | Online double conversion |
| Configuration | Tower |
| Part Number | 9E10Ki |
| Rating (VA/Watts) | 10000/8000 |
| Dimensions (H x W x D, mm) | 708.5 x 262.4 x 612.9 |
| Weight (kg) | 85.4 |
| Warranty | 1 year |
| Electrical Input | |
| Connection |
Hardwired – see manual for terminal block layout
|
| Input Voltage Range | 176-276V without derating (up to 110-276V with derating) |
| Nominal Voltage | 220/230/240V |
| Frequency | 50/60 Hz autoselection |
| Frequency Range | 45-66 Hz |
| Short Circuit Current | 137 A |
| Electrical Output | |
| Voltages | 220V/230V/240V ±2 % |
| Voltage THD | <3% |
| Outlets |
Hardwired – see manual for terminal block layout
|
| Overload Capacity | 105%-110% : 5min, 110%-130% : 1min, 130%-150% : 10s, >150% : 100ms |
| Efficiency (Normal Mode) | Up to 93% in Online mode, 97% in ECO mode |
| Output Frequency | 50/60 Hz autoselect |
| Communications | |
| Communication Ports | 1 USB port + 1 RS232 serial port (USB and RS232 ports cannot be used simultaneously) |
| Communication Slot | 1 slot for Network-M2, ModBus-MS or Relay-MS cards |
| Power Management Software | Intelligent Power Software |
| Environmental & Standards | |
| Audible Noise | <55dB |
| Operating Temperature | 0 to 40°C |
| Safety markings | IEC/EN 62040-1 |
| EMC Markings | IEC/EN 62040 -2 |
| Approvals | CE, CB report (TUV) |
