Key Features of the CCR1016-12S-1S+

The CCR1016-12S-1S+ is a high-performance router designed for demanding network environments. Here are its key technical features:

Powerful Processing

• 16-core Tilera CPU: This powerful processor enables the router to handle massive amounts of traffic and complex routing tasks.
• 1.2 GHz per core: High clock speed for efficient processing.

Flexible Connectivity

• 12 x 1 Gigabit SFP ports: Provides ample connectivity for various network devices.
• 1 x 10 Gigabit SFP+ port: Enables high-speed data transfer.

Robust Design

• 1U rackmount case: Compact and easy to deploy in standard 19-inch racks.
• Redundant power supplies: Ensures continuous operation in case of power failures.
• Wide operating temperature range: Suitable for various environments.

User-Friendly Interface

• Color touchscreen LCD display: Provides easy access to system information and configuration.
• RJ45 console port: Enables local management and troubleshooting.
• USB Type-A port: Supports external storage and configuration backups.

Advanced Routing Capabilities

• RouterOS, License Level 6: Powerful and flexible networking operating system.
• High-performance routing: Handles millions of packets per second.
• VPN support: Supports various VPN protocols for secure remote access.
• Firewall capabilities: Protects networks from unauthorized access.

General Specifications:

• Model: MikroTik CRS328-24P-4S+RM
• Form Factor: 1U Rack-mountable
• Switching Capacity: 64 Gbps
• Forwarding Rate: 95.2 Mpps
• Total Non-blocking Throughput: 32 Gbps
• Operating System: Dual boot - MikroTik RouterOS (Level 5) or SwOS

Ports:

• Gigabit Ethernet Ports: 24 x 10/100/1000 Mbps ports
• SFP+ Ports: 4 x SFP+ (10Gbps) for fiber connections
• Console Port: 1 x RJ45 Serial Console Port

PoE Features:

• PoE Standards: Passive PoE, 802.3af/at PoE-Out
• PoE-Out Ports: 24 Gigabit Ethernet ports support PoE-out
• Total Power Budget: Up to 500W power output for PoE devices
• PoE Voltage Range: 12-57V

Performance:

• CPU: 800 MHz Dual-Core Processor
• RAM: 512 MB
• Flash Storage: 16 MB
• Switch Chip: 98DX3236

Power and Cooling:

• Power Supply: Dual Redundant Power Supply (100-240V AC)
• Max Power Consumption: 44W (without PoE devices) / 494W (with PoE devices)
• Cooling: Active cooling with built-in fans

Layer 3 Features:

• Routing: Static routing, RIPv1/v2, OSPF
• VLAN Support: 802.1Q VLAN
• Security: Port isolation, DHCP snooping, IP filtering
• QoS: Bandwidth control, priority tagging

Dimensions & Weight:

• Dimensions: 443 x 300 x 44 mm (17.4 x 11.8 x 1.7 inches)
• Weight: 4.5 kg (9.92 lbs)

Operating Conditions:

• Operating Temperature: -20°C to 60°C (-4°F to 140°F)
• Humidity: Up to 95% non-condensing

Additional Features:

• Web Management Interface: Available via RouterOS or SwOS
• Monitoring: Voltage, temperature, and current monitoring
• LED Indicators: Power, Link/Activity, PoE status

These specifications outline the robust capabilities of the MikroTik CRS328-24P-4S+RM, making it an excellent choice for network administrators who need a flexible, high-performance switch with powerful PoE capabilities.
