APC Easy UPS On-Line SRV 1000VA RM 230V with Rail Kit (SRV1KRIRK)

The APC Easy UPS On-Line SRV 1000VA RM 230V with Rail Kit (SRV1KRIRK) is a reliable rackmount uninterruptible power supply designed to provide continuous, clean, and stable power for critical IT equipment. Featuring true online double-conversion technology, a 1000VA/800W output capacity, and pure sine wave output, this UPS delivers advanced protection against power outages, voltage fluctuations, surges, spikes, and electrical noise. Its compact 2U rackmount design, included rail kit, intelligent battery management, and LCD monitoring make it ideal for servers, networking equipment, telecommunications systems, security devices, and business IT environments.

Product Features

1000VA / 800W Power Capacity

Provides 1000VA and 800W of continuous output power, making it suitable for protecting servers, network switches, storage systems, and other essential business equipment.

True Online Double-Conversion Technology

Continuously converts incoming AC power to DC and back to AC, providing complete isolation from voltage fluctuations, surges, spikes, electrical noise, and power interruptions.

Pure Sine Wave Output

Produces a clean and stable sine wave output, ensuring compatibility with sensitive electronic equipment and devices requiring high-quality power delivery.

2U Rackmount Design with Rail Kit

Designed for installation in standard server racks, the 2U rackmount form factor helps save rack space while the included rail kit allows secure and convenient installation.

Zero Transfer Time

Provides uninterrupted power during utility failures with online double-conversion operation, ensuring continuous protection for connected devices.

Wide Input Voltage Range

Supports a wide input voltage range, allowing reliable operation even in environments with unstable power conditions.

Multifunction LCD Display

The LCD control panel provides real-time information including operating mode, input and output parameters, battery status, load level, and system alarms.

Intelligent Battery Management

Optimizes battery charging and monitoring to extend battery lifespan and improve backup reliability.

Communication and Remote Monitoring

Supports USB and RS-232 communication interfaces with SmartSlot compatibility for local monitoring and optional network management.

Automatic and Manual Bypass

Includes bypass functionality to maintain power delivery during overload conditions or maintenance operations.

Comprehensive Equipment Protection

Protects connected equipment against overload, short circuits, surges, overvoltage, undervoltage, overheating, overcharging, and deep battery discharge.

Product Specifications

• Brand: APC
• Model: SRV1KRIRK
• Product Type: Online Rackmount UPS
• UPS Topology: True Online Double-Conversion
• Capacity: 1000VA (1KVA)
• Output Power: 800W
• Form Factor: 2U Rackmount
• Rail Kit: Included
• Input Voltage: 230V AC
• Input Frequency: 40–70Hz Auto-Sensing
• Input Connection: IEC 60320 C14
• Output Voltage: 220V / 230V / 240V AC (Selectable)
• Output Frequency: 50/60Hz
• Waveform: Pure Sine Wave
• Output Connections: 3 × IEC C13
• Load Crest Factor: 3:1
• Transfer Time: 0ms
• Battery Type: Sealed Maintenance-Free Lead-Acid Battery
• Battery Voltage: 24V
• Typical Recharge Time: Approximately 4 Hours
• Expected Battery Life: 3–5 Years
• Display: Multifunction LCD Status and Control Console
• Communication Interfaces: USB, RS-232
• Network Management: SmartSlot Support for Optional Network Management Card
• Bypass: Automatic and Manual Internal Bypass
• Surge Protection: Yes
• Audible Alarm: Yes
• Rack Height: 2U
• Dimensions: 86mm × 437mm × 312mm
• Weight: Approximately 11kg
• Generator Compatible: Yes
• Colour: Black
